Sipura / Linksys Phone Adapter ATA + PSTN Router Gateway (1x FXS / 1x FXO Port)

The SPA-3102 features VoIP adapter functionality found in the SPA-2000/2 and SPA-1000/1 with the additional benefit of an integral connection for legacy telephone network ?hop-on, hop-off? applications. SPA-3102 users will be able to leverage their broadband phone service connections more than ever by automatically routing local calls from cell phones and land lines to a VoIP service provider and vice versa.

A typical user calling from a land line or mobile phone will be able to reduce and even eliminate international and long distance telephone charges by first calling their SPA-3102 via a local phone number or by using a telephone connected directly to the unit. The advanced authentication and call routing intel-ligence programmed into the SPA-3102 will connect the caller via the Internet to the far end destination with security and ease. Using the SPA-3102 at the far end, calls can be answered immediately or further processed as a local call to any legacy land line or mobile phone allowed by the SPA-3102 dial plan.

If power and/or IP network connectivity is lost to the unit or the VoIP service is down, calls can be sent to a traditional carrier via the FXO interface.

Application Note:

The SPA-3102 complies with:
- Part 68 United States FCC Regulations.
- ETSI TS 103 021 - 1, 2, 3
- Australian ACIF S002: 2001
Additional compliance (per country) is forthcoming.

Feature:

1x WAN
1x LAN
1x FXS (RJ11)
1x FXO (RJ11)
Gateway + Router + QoS = Quality of Service
Codec: G.711, G.723.1, G.726, G.729.A
Fax Protocol: T.38

Free Configuration:

AOL, AXXESO, 1&1, dus.net, freenet, GMX, nikotel, sipcall.ch, sipgate, sipphone.com (Gizmo), sipsnip, T-Online, toplink, QSC-AG, web.de, SIPDiscount.com, VoipBuster.com, VoipStunt.com, VoipCheap.com, T2 (siect2.pl), Newfone (newfon.pl) and more + Help by moderated Forum
